Chapter 4 Panel Display and Operation ASDA-M
4-2 Revision December, 2014
4.2 Parameter Setting Procedure
4.2.1 Axis Switching Procedure
(1) When the servo drive connects to the power, the display will show the monitor variable
for about one second, and then enter into the Monitor Mode.
(2) The single-group of seven-segment display shows the current selected axis. After
connecting to the power, if the servo drive displays 1, it means the current selected axis
is the first axis (X axis).
(3) SEL Key can used to select the axis. The number increases every time the user
presses the SEL Key. The order is like a cycle: 1(X axis) → 2(Y axis) → 3(Z axis) →
1(X axis).
(4) After setting the axis, it will enter the corresponding setting procedure of parameters.
(5) The setting of parameter corresponds to each axis respectively.
NOTE
When there is an alarm, the display will stay at the axis which has error
and show the alarm code. SEL Key has no function at the moment. Not
until pressing the MODE Key to switch to the other modes, can the SEL
Key be used to select the axis. If there is no Key to be pressed for 20
seconds, it will return to the Alarm Mode automatically.
