Chapter 7 Memory Card
7.4
Memory Card Contents
7.4.1
Initializing a Memory Card
When you insert an SDHC card into a CPU module that is powered on, and use ISPSoft -> CARD Utility to back
up a project, the system initializes the SDHC card, and creates a default folder named according to the model
of the CPU module. (If the folder is already existed, the system does not create a second folder for the same
model.)
When the system initializes an SDHC card, it automatically adds any missing folders to the directory structure.
However, if the initialization of a SDHC card fails, you cannot initialize the SDHC card again until you reformat it.
When you initialize a memory card, the SYSTEM indicator in the software blinks.
7.4.2
Folder Structure in a Memory Card
The image below shows the default folder group created by a DVP-ES3 Series System. The folder name is
ES3. Several subfolders are contained inside the ES3 folder. Related files created by you and the DVP-ES3
Series system are stored in the subfolders.
PLC CARD
Log
