Delta DVP32ES300T User Manual

Chapter 9 Ethernet Specification and Operation
9-47
9_
Configuration
0x86
Refer to the table below
Connection 8
Input (TO)
0x73
D1700~D1799
Output (OT)
0x72
D700~D799
Configuration
0x87
Refer to the table below
Configure the contents of input and output to edit the mapping address.
Configuration
Address
Data Type Contents
Defaults
(Connection 1)
Word[0] UINT
Input corresponding element
0: D, 1:X, 2: Y
0
Word[1] UINT Reserved 200
Word[2-3] DWORD Input corresponding element number 1000
Word[4] UINT
Output corresponding element
0: D, 2: Y
0
Word[5] UINT Reserved 200
Word[6-7] DWORD Output corresponding element number 0
9.7.6 Connection Manager Object (Class ID: 06 Hex)
Use this object for connection and connectionless communications, including establishing connections across multiple
subnets.
 Service Code
Service
Code
Service Name
Support
Description
Class Attribute Instance Attribute
H’0E Get_Attribute_Single V X Read a single attribute
H’4E Forward_Close X V Close a connection
H’54 Forward_Open X V
Open a connection; the maximum
data size is 511 bytes.
 Class
 Class ID：H’06
