CHAPTER 6 TROUBLESHOOTING GUIDE
2-3. Glue Problem
Symptom Cause Solution
Glue is not applied to
the spine.
There is not enough hot melt glue in the
glue tank.
Add hot melt glue. ( p.2-3)
The glue temperature is too high. Change the temperature of the glue tank
according to the specification of the hot
melt glue you are using. ( p.4-18)
The spine meter roller is not in the
appropriate position.
Adjust the position of the spine meter
roller. ( p.4-10)
The No.1 and No.2 glue drum meter
adjustments are not adjusted properly.
Adjust the No.1 and No.2 glue drum
meter adjustments properly. ( p.4-10)
The book block was not placed in the
clamp properly.
Place the book block in the clamp
properly. ( p.3-2)
The glue cutting position is not adjusted
properly.
Adjust the glue cutting position on the
touch panel screen. ( p.4-8)
Too much glue is
applied to the spine.
The glue temperature is too low. Change the temperature of the glue tank
according to the specification of the hot
melt glue you are using. ( p.4-18)
The spine meter roller is not in the
appropriate position.
Adjust the position of the spine meter
roller. ( p.4-10)
The No.1 and No.2 glue drum meter
adjustments are not adjusted properly.
Adjust the No.1 and No.2 glue drum
meter adjustments properly. ( p.4-10)
The glue cutting position is not adjusted
properly.
Adjust the glue cutting position on the
touch panel screen. ( p.4-8)
The edge of the book
block on the operator's
side is dented.
The side glue roller is not properly
positioned.
Increase the distance between the side
glue rollers. ( p.4-9)
The edge of the book
block on the non-
operator's side is
dented.
The side glue roller is not properly
positioned.
Adjust the position of the side glue roller
(non-operator's side). ( p.2-7)
The color of the hot melt
glue has changed.
The glue in the glue tank has
deteriorated.
Replace the glue. ( p.5-6)
Smoke is rising from the
glue tank.
The tank temperature is higher than
specified for the hot melt glue you are
using.
Change the temperature of the glue tank
according to the specification of the hot
melt glue you are using. ( p.4-18)
The hot melt glue
amount in the glue tank
gets low unusually fast.
The drain bolt is not fastened. Fasten the drain bolt. ( p.5-8)
Too much glue is
applied to the side of the
book block.
The side glue meter is not in the
appropriate position.
Adjust the position of the side glue
meter. ( p.4-10)
Too much glue is applied to the spine of
the book block.
Adjust the position of the No.1 glue
drum meter adjustment, No.2 glue drum
meter adjustment and spine meter roller
adjustment. ( p.4-10)
Glue is not applied to
the side of the book
block.
The side glue meter is not in the
appropriate position.
Adjust the position of the side glue
meter. ( p.4-10)
