Duplo DPB-500 User Manual

7-2
CHAPTER 7 APPENDIX
1. Specification
Model DPB-500
Type
Floor model
The Number of Clamp 1
Type of Binding Binding with a cover, binding without a cover
Booklet Size
Book Block Binding thickness 1 to 51 mm (0.04 to 2.01 inches) +cover thickness
Maximum size 360 (length) x 320 (height) mm / 14.17 (length) x 12.6 (height)
inches
Minimum size 120 (length) x 120 (height) mm / 4.72 (length) x 4.72 (height) inches
Book block form Sheet, single-folded, double-folded*
Paper type Fine 52 to 157 g/m²
Art/Coated 79 to 157 g/m²
Cover Feeding method Belt suction
(Separating air, separator manual non-step adjustment)
Maximum size 360 (length) x 696 (width) mm/
14.17 (length) x 27.4 (width) inches
Minimum size 120 (length) x 250 (width) mm/
4.72 (length) x 9.84 (width) inches
Paper curl 5 mm (0.2 inch) or less R60 or more
(No wavy paper, flatten a curled cover.)
Paper type Fine 81.4 to 302 g/m²
Art/Coated 104.7 to 302 g/m²
Stack height 70 mm/2.76 inches (if the length is 170 mm/2.76 inches or
shorter, 40 mm/1.57 inches)
Maximum Binding
Speed
525 cycle/hour
Milling Maximum 4 mm/0.16 inch
(Manual 6 step adjustment: 0, 0.5, 1.0, 2, 3, 4 mm / 0, 0.02, 0.04, 0.08, 0.12, 0.16 inch)
Roughening 2 pieces
Gluing Glue thickness 0.5 to 2.25 mm / 0.02 to 0.09 inch (adjust the height of the
drums manually)
Drum 2 + spine meter roller
Side glue Roller method
Glue cutting Solenoid-driven
Warm-up period Approximately 30 minutes (varies depending on the hot melt
glue type and environment)
Scoring The number of
score
Each 2 on the operator's side and non-operator's side (spine
and hinge)
Depth adjustment Manual non-step adjustment
Ream weight 157g/m² or more (The use of less than 157g/m² may cause skew.)
Scoring width 3 to 51 mm (no scoring for a book block with a thickness of
less than 3 mm)
Nipping Height adjustment Manual non-step adjustment
Stacker Stacking method Vertical stack
Stack height Maximum 200 mm/7.87 inches
Noise Emission 90 dB or less
Ratings
Three-phase Y208 V, 240 V 60 Hz (USA, Canada), Three-phase Y380 to Y415
V 50/60 Hz (Europe)
Power Consumption 3.2 kw 8A/single-phase (USA, Canada), 3.2 kw 5 A/single-phase (Europe)
Dimensions 2790 (W) × 928 (D) × 1343 (H) mm / 109.84 x 36.54 x 52.87 inches
Weight (Mass)
695 kg/1529 Ib.
Option Wing scoring, long stacker, barcode kit
Design and specifications are subject to change without notice.
* Folded paper that cannot be clamped because of the folding condition is considered to be out of specification.
