Fronius CMT 4000 Advanced Operating Instructions & Spare Parts

127
EN
Job correction
General
Job correction menu: Overview
In the Job correction menu, setup parame-
ters can be adapted to the specific require-
ments of individual jobs.
Opening the Job
correction menu
Press and hold the Store button
Press the parameter selection button (left)
Release the Store button
The power source is now in the Job correction menu. The first parameter,
"Job", is shown. The "Job" parameter is used to select the job for which the
parameters are to be adjusted.
The job correction menu can also be opened using the following:
- RCU 4000 remote control
- Win RCU (JobExplorer software)
- ROB 4000/5000 robot interface
- Field bus systems
Changing weld-
ing parameters
Use the Process button to select the desired parameter
Use the adjusting dial to change the parameter value
Exiting the Job
correction menu
Press the Store button
1
2
3
1
2
NOTE! Any alterations are saved by exiting from the Job correction menu.
1
