181
EN
Technical data
Special voltages For devices designed for special voltages, the technical data on the rating plate applies.
For all machines with a permitted mains voltage of up to 460 V: The standard mains plug
allows the user to operate with a mains voltage of up to 400 V. For mains voltages up to
460 V fit a mains plug permitted for such use or install the mains supply directly.
TPS 2700
Mains voltage 3 x 400 V
Mains voltage tolerance +/- 15 %
Mains frequency 50 / 60 Hz
Mains fuse protection 16 A slow-blow
Mains connection
1)
Z
max
at PCC
2)
= 95 mOhm
Primary continuous current 100% d.c.
3)
6.6 A
Primary continuous power 4.5 - 8.7 kVA
Cos phi 0.99
Efficiency 87 %
Welding current range
MIG/MAG 3 - 270 A
Rod electrode 10 - 270 A
TIG 3 - 270 A
Welding current at
10 min / 40 °C (104 °F) 40 % d.c.
3)
270 A
60 % d.c.
3)
270 A
100% d.c.
3)
170 A
Welding voltage range according to standard characteristic
MIG/MAG 14.2 - 27.5 V
Rod electrode 20.4 - 30.8 V
TIG 10.1 - 20.8 V
Max. welding voltage 34.6 V
Open circuit voltage 50 V
Degree of protection IP 23
Type of cooling AF
Insulation class B
EMC emission class A
Marks of conformity CE, CSA
Safety symbol S
Dimensions l x w x h 641.5 x 297.4 x 476.5 mm
25.26 x 11.71 x 18.76 in.
Weight 27 kg
59.5 lb.
Supply voltage in wire-feed unit 55 V DC
Nominal current in wire-feed unit 4 A
Wire feed speed 0.5 - 22 m/min
19.69 - 866.14 ipm
