34
Standard control panel
General
Any changes to the “Welding current” and “Arc-length correction” parameters have to be
made on the wire-feed unit.
Standard control
panel
NOTE! On the Standard control panel, only the MIG/MAG standard synergic
welding process is available. The following processes and functions are not avail-
able and cannot be retrofitted:
- MIG/MAG pulse synergic welding
- Job mode
- TIG welding
- Manual metal arc welding
- Spot welding
No. Function
(1) Feeder inching button
for feeding the wire electrode into the torch-hosepack without any flow of gas or
current
For information on the various wire feed sequences that are possible when the
welder presses and holds the "Feeder inching" button, see the Fdi parameter in
the Setup menu.
(3) (5)
(15)(14)
(6) (9) (10)(8)(7)(4)
(13)
(12) (11)
(2)(1)
(16)
