Fronius CMT 4000 Advanced Operating Instructions & Spare Parts

184
1)
connected to public grid at 230/400 V and 50 Hz
2)
d.c. = Duty cycle
TPS 3200 MV
Open circuit voltage 65 V
Degree of protection IP 23
Type of cooling AF
Insulation class F
EMC emission class A
Marks of conformity CE
Safety symbol S
Dimensions l x w x h 626 x 287 x 477 mm
24.65 x 11.30 x 18.78 in.
Weight 34.6 kg
76.3 lb.
Mains voltage 3 x 200-240 V
3 x 380-460 V
Mains voltage tolerance +/- 10 %
Mains frequency 50 / 60 Hz
Mains fuse protection 35 A slow-blow
Mains connection
1)
Restrictions possible
Primary continuous current 100% d.c.
2)
10.6 - 31.2 A
Primary continuous power 8.7 - 11.5 kVA
Cos phi 0.99
Efficiency 90 - 91 %
Welding current range
MIG/MAG 3 - 320 A
Rod electrode 10 - 320 A
TIG 3 - 320 A
Welding current at
10 min / 40 °C (104 °F) 40 % d.c.
2)
320 A
60 % d.c.
2)
260 A
100% d.c.
2)
220 A
Welding voltage range according to standard characteristic
MIG/MAG 14.2 - 30.0 V
Rod electrode 20.4 - 32.8 V
TIG 10.1 - 22.8 V
Max. welding voltage (320 A) 49.1 - 63.1 V
Open circuit voltage 64 - 67 V
Degree of protection IP 23
Type of cooling AF
Insulation class F
EMC emission class A
Marks of conformity CE, CSA
Safety symbol S
