40
(14) Droplet detachment correction/arc force dynamic correction/arc force dy-
namic LED
lights up when the droplet detachment correction/arc force dynamic correction/
arc force dynamic parameter is selected
(15) Welding voltage LED
lights up when the welding voltage parameter is selected
(16) Welding speed LED
lights up when the welding speed parameter is selected
(17) Right digital display
(18) Job no. LED
lights up when the job number parameter is selected
(19) F3 indicator LED
lights up when the F3 indicator parameter is selected
(20) Parameter selection button
for selecting the following parameters:
Arc length correction
for correcting the arc length
Droplet detachment correction/arc force dynamic correction/arc
force dynamic
has a different function assigned to it, depending on the process being
used. A description of the various functions can be found in the Welding
chapter under the corresponding process.
Welding voltage
Welding voltage in V
Before the start of welding, the machine automatically displays a stand-
ard value based on the programmed parameters. During welding, the
actual value is displayed.
Welding speed
Welding speed in cm/min or ipm (necessary for the a-dimension param-
eter)
Job N
o
In the job mode process for retrieving parameter records stored under
job numbers
F3 indicator
indicates the real energy inputs in KJ. The real energy input must be ac-
tivated in level 2 of the Setup menu – parameter EnE. If the indicator is
not activated, the coolant flow is displayed when the coolant device FK
4000 Rob is available.
If the indicators are lit up on the parameter selection button (20) and on the ad-
justing dial (21), then the indicated/selected parameter can be altered using the
adjusting dial (21).
(21) Adjusting dial
for altering parameters. If the indicator on the adjusting dial is lit up, then the se-
lected parameter is one that can be altered.
No. Function
