PC Specialist's Handbook ErgoPro e-, x- and s- Series

First Edition, Release 4 - June 1998 Page 21

6-slot PCI/ISA back plane AC41637

ISA-slot connectors

System board connector

Note : there are no jumpers on the board

PCI-slot connectors

1 32

Picture 27 : 6-slot PCI/ISA back plane AC41637

Ethernet module AC41635

Note : there are no jumpers on the board

Picture 28 : Ethernet module
