Fujitsu ErgoPro e Series User Manual

PC Specialist's Handbook ErgoPro e-, x- and s- Series
First Edition, Release 4 - June 1998 Page 75
SCSI port connector
1
25
2650
PIN Signal
1-12
Signal ground
13
Open
14-25
Signal ground
26
Data bit 0
27
Data bit 1
28
Data bit 2
29
Data bit 3
30
Data bit 4
31
Data bit 5
32
Data bit 6
33
Data bit 7
34
Data parity bit
35-37
Signal ground
38
Termination power
39-40
Signal ground
41
ATN
42
Signal ground
43
BSY
44
ACK
45
RST
46
MSG
47
SEL
48
C/D
49
REQ
50
I/O
