Furuno FELCOM 500 Service Manual

Summary
10
The relevant setup values are described regardless of the default values.
*** Web MMI ***
Setup item Setup menu Notes
Reference
page
Mandatory)
IP addresses
allocated
automatically
Settings -> Network
settings -> LAN -> IP
address
If you set DHCP to Use, the IP
addresses will be allocated
automatically
4-10
7-1
Mandatory)
Connecting analog
phone/FAX
Settings -> Basic settings
-> Analog ports
Set the terminal to be connected to
ports TEL1-4
4-7
Mandatory)
Registering Handset
extension numbers
and passwords
Settings -> PBX settings ->
Extension
Registering in the SIP server
They are to match with the
extension numbers and passwords
set in the Handsets.
4-12
Incoming routes
Settings -> PBX settings ->
Incoming routing
Set where the phone call / FAX
communication is to be received
and its route.
4-20
Call limitations
Settings -> PBX settings ->
Call limit
Limitations for making
external/extension calls; not
setting required for receiving calls
4-25
Grouping extension
calls
Settings -> PBX settings ->
Group
To be set as necessary 4-26
Ringing settings for
the Incoming
indicator
Settings -> Basic settings
-> Incoming indicator
Ringing settings for the phone,
FAX, UDI, and RDI
4-28
Echo canceller
function ON/OFF
Service -> Echo canceller
ON/OFF setting for the echo
canceller for the Communication
unit
10-31
Satellite searching
method
Main -> Satellite search
Place a tick in Search all satellite
automatically.
10-7
Backup GPS
Settings -> Basic settings
-> GPS
Set to 4800 bps. 10-8
WAN service setting
Settings -> Network
settings -> WAN
Set the allowed Streaming service
(Standard is allowed)
5-2
WAN APN setting
Settings -> Network
settings -> WAN -> Setting
-> APN
APN for "(SIM) -----" is to be
selected.
5-5
UDI/RDI setting
Settings -> Basic settings
-> Serial port
 Baud rate: 115200 bps
 Parity: None
 Flow control: Hardware
6-1
