Garmin G5 Installation Manual

Garmin G5 Electronic Flight Instrument Part 23 AML STC Installation Manual 190-01112-10
Rev. 21
Page 15
1.4 STC Permission
A permission letter to use this STC data is available for download for each authorized G5 installation. The
STC Installation Kit contains instructions for downloading the STC permission letter from
www.Garmin.com. Contact a local Garmin Dealer for G5 Attitude, G5 DG and G5 HSI STC Kit Part
Numbers.
1.5 Scope
This manual applies to the modification of an aircraft listed on the Part 23 AML STC SA01818WI for the
installation of equipment listed below. Only the interfaces between the Garmin G5 Electronic Flight
Instrument and equipment listed in this manual are approved by the STC.
Table 1-2 G5 Attitude and G5 DG/HSI Equipment
Model
Nomenclature
Unit P/N
Mod
Status
Catalog P/N
Software P/N
and Version
G5
Electronic Flight Instrument
011-03809-00
--
010-01485-00
006-B2304-XX*
G5
Installation Kit
011-03892-00
--
010-12493-10
N/A
G5
Battery pack
011-03893-00
--
010-12493-00
N/A
GMU 11
Magnetometer
011-04349-01
--
010-01788-01
006-B2770-XX*
GMU 11
GMU 11 Installation Kit
011-04349-90
--
010-01788-01
N/A
GAD 29
Data Bus Converter
011-03236-01
--
010-01172-01
006-B1760-XX*
GAD 29B**
Data Bus Converter
011-03236-11
--
010-01172-11
006-B1760-XX*
GAD 29/29B
GAD 29/29B Connector Kit
011-03271-00
--
N/A
N/A
GPS Antenna,
TNC
Glareshield mount GPS
antenna
011-04036-00
--
010-12444-00
N/A
TNC/BNC Adapter
Coax adapter for
glareshield antenna
330-01754-00
--
--
N/A
GAD 13
Unit Only
011-04938-00
--
010-02203-00
N/A
GAD 13
Connector Kit
011-03002-10
--
N/A
N/A
GTP 59
OAT Probe Installation Kit
494-00022-08
--
011-00978-00
N/A
* The approved G5 Part 23 AML STC Electronic Flight Instrument software is P/N 006-B2304-XX.
XX denotes the specific version P/N, i.e. 006-B2304-02 is software version 2.60. The G5 Electronic Flight
Instrument, GMU 11 Magnetometer and GAD 29/29B listed above is shipped with approved software. To
verify the latest approved software visit www.Garmin.com and navigate to the Aviation /General
Aviation/Flight Instruments & Indicators/G5 page. Select ‘Software” in the overview tab.
** The GAD 29B is only required in installations that utilize the G5 heading and course output to an autopilot,
or interface with a Garmin navigator.

Garmin G5 Specifications

General

Brand	Garmin
Model	G5
Category	Avionics Display
Language	English
