Garmin G5 Electronic Flight Instrument Part 23 AML STC Installation Manual 190-01112-10
Rev. 21
Page 83
Table 4-4: G5 (1P51, 2P51), GMU 11 (P111), and GAD 13 (P131) Connector Parts
Item
Description
Part Number
Notes
1
Shield Termination, Solder Style, Insulated, Heat-Shrinkable,
Environment Resistant (X = size)
AS83519/1-X
(SAE-AS83519)
1
2
Contact, Socket, MIL Crimp, Size 20
M39029/63-368, or
336-00022-02
2
3
Insulation Tape, Electrical, Self-Adhering, Unsupported Silicone
Rubber
A-A-59163
(MIL-I-46852C)
4
Terminal, Lug, Crimp Style, Copper, Insulated, Ring Tongue,
Bell Mouthed, Type II, Class I
MS25036-149
5
Connector, Plug, D-Sub, MIL Crimp Socket
330-00625-09
2
6
Backshell, Jackscrew, 9/15 Pin
125-00171-00
2
7
Clamp, Backshell, Jackscrew, 9/15 Pin
115-01078-00
2
8
Screw, 4-40x.375, PHP, SS/P, w/Nylon
211-60234-10
2
9
Cover, Backshell, Jackscrew, 9/15 Pin
115-01079-00
2
10
Screw, 4-40x.187, FLHP100, SS/P, w/Nylon
211-63234-06
2
11
Screw, PHP, 8-32 x 0.312", Cad-Plated Steel, or
Screw, PHP, 8-32 x 0.312", Stainless
MS35206-242, or
MS51957-42
12
Split Washer, #8 (0.045" compressed thickness), Cad-plated
Steel, or
Split Washer, #8 (0.045" compressed thickness), Stainless
MS35338-42, or
MS35338-137
13
Flat washer, Cad-plated Steel, #8, 0.032" thick, 0.174" ID,
0.375" OD, or
Flat Washer, Stainless, #8, 0.032" thick, 0.174" ID, 0.375" OD
NAS1149FN832P,
or
NAS1149CN832R
14
Flat Braid, 1/16”
AA59569F36T0062
1
Notes:
1. AS83519/1-X and braid are the preferred method for shield termination. Alternately, AS83519/2-
X with pre-installed shield drain may be used.
2. Garmin Part Number. Included in kit p/n 011-03002-00/10.
This area intentionally blank
