Garmin G5 Electronic Flight
Instrument Part 23 AML STC Installati
on Manual
190
-01112-
10
Rev. 21
Page
225
A.5
GTP 59
Figure 6-
12
GTP 59
PIN
WIRE
I/O
WH
TEMP PROBE POWER IN
IN
BL
TEMP PROBE OUT HI
OUT
OR
TEMP PROBE OUT LO
OUT
A.5.1
OAT Sensing
The GTP 59 is an OAT sensing device. The con
nection to thi
s LRU is made via pre-installed lead wires,
if they are not long enough to reach the
GAD 13, crimp splices can be u
sed to extend the lead wire to the
GAD 13. The p
re
-installed lead wires are
ten feet in length.
For specific wiring information, refer to
Section 5.
This area intentionally blank
