Garmin G5 Electronic Flight
Instrument Part 23 AML STC Installati
on Manual
190
-01112-
10
Rev. 21
Page
71
Screws
MS35206-XXX OR AN525
832RXX
(#8, Length A/R)
Washers
NAS1149FN8
XX
P
OR
#8
Nutplates
Standard Part; Any MS (Mil-Spe
c) Part Number
Nuts
MS21044N08
Rivets
MS20426AD3-X
Countersunk Screws
#8 MS24693-
XXX
Washers
NAS1149FN832P
Nuts
MS21044N08
Figure 4-
40
GAD 29/29B
Mounting Hardware
70
72
