Garmin G5 Electronic Flight
Instrument Part 23 AML STC Installati
on Manual
190
-01112-
10
Rev. 21
Page
169
Figure 5-
22
Dual G5 wit
h Two-Inch GPS Navigator Notes
5.18.1
Attitud
e In
dicato
r Config
uration
Config Page
Config Option
Configuration Setting
Device Information
Installation Type
Certified Instrument
Diagnostics/Data Log
Enabled
At
titude Configuration
Indicator Type
Normal
Pitch Display
Normal
Roll Display
For Fixed Type Pointers G5 Config =
Ground Pointer
or
For Movable Type Pointers G5 Co
nfig = Sky Pointer
Standard Turn Roll Reference
Hide
Automatic Declutter
Enabled
Air Data
Air Data Sensors
Enabled
Vertical Speed Indicator
(1)(2)
Airspeed
Note: Configure Units prior to setting
airspeeds.
VNE
(1)(2)(3)
VNO
(1)(2)(3)
VSO
(1)(2)(3)
VS1
(1)(2)(3)
VFE
(1)(2)(3)
VA
(1)(2)(3)
VX
(1)(2)(3)
VY
(1)(2)(3)
VG
(1)(2)(3)
VR
(1)(2)(3)
VMC
(1)(2)(3)
VYSE
(1)(2)(3)
Magnetometer
Magnetometer
Enabled
Orientation
Connector Aft
Or
Connector Forward
168
170
