Garmin G5 Installation Manual

Garmin G5 Electronic Flight Instrument Part 23 AML STC Installation Manual 190-01112-10
Rev. 21
Page 214
c. For each VHF NAV radio, monitor one local frequency, one remote (far field) frequency,
and one unused frequency.
d. Make sure there are no guidance errors.
e. Make sure there are no audio tones that interfere with the station ID.
f. For each GPS Navigator, enter a simple flight plan and display as appropriate. i.e.
Navigator Display, G5, HSI, CDI etc., if installed.
g. Make sure there are no guidance errors.
9. Make sure all other avionics properly function.
VICTIM
G5 #1
G5 #2 (
If installed)
GMU 1
1 (If installed)
GAD 29/29B
(If installed)
GAD 13
(if installed)
Magnetic Compass
Clock
OAT Indicator
Power Plant Instruments
Autopilot / SAS
Navigation
Radio(s)
Communication Radio(s)
Engine Relight
Fuel Valve
Pitot Heat
Pulse Light
Generator
Pos Lt
Anti Coll Lt
Ldg Lts
Gov RPM Incr / Decr
Eng Deicing
Hyd System
Radar Altimeter
TAS/TCAS
Transponder
Audio Panel
GTX 3X5
<add equipment here>
<add equipment h
ere>
SOURCE
G5 #1
G5 #2
(If installed)
GMU 11
(If installed)
GAD 29/29B
(If installed)
GAD 13
(if installed)
Magnetic
Compass
Clock
OAT Indicator
Power Plant
Instruments
Autopilot / SAS
Navigation
Radio(s)
Communication
Radio(s)
Engine Relight
Fuel Valve
Pitot Heat
Pulse Light
Generator
Pos Lt
Anti Coll Lt
Ldg Lts
Gov RPM Incr /
Decr
Eng Deicing
Hyd System
Radar Altimeter
TAS/TCAS
Transponder
Audio Panel
GTX 3X5
<add
equipment
here>
Figure 6-6 Example EMC Source/Victim Matrix
