Garmin G5 Electronic Flight
Instrument Part 23 AML STC Installati
on Manual
190
-01112-
10
Rev. 21
Page
222
A.3
GAD 29/29B
A.3.1
J291
Figure 6-9 J291 on the G
AD 29/29B
J291 Pin Descriptions
Pin
Pin Name
I/O
1
CAN
-H
I/O
2
CAN
-L
I/O
3
RESERVED
--
4
RESERVED
--
5
RESERVED
--
6
GROUND
--
7
AIRCRAFT POWER 1
In
8
AIRCRAFT POWER 2
In
9
GROUND
--
A.3.2
J292
Figure 6-
10
J292 on
the GAD 29/29B
J292 Pin Descriptions
Pin
Pin Name
I/O
1
AC REFERENCE HI
(GAD 29B ONLY)
In
2
AC REFERENCE LO
(GAD 29B ONLY)
In
3
HDG/CRS VALID
(GAD 29B ONLY)
Out
4
ARINC 429
RX
4B
In
5
ARINC 429
RX
3B
In
6
ARINC 429
TX
2B
Out
221
