6–8 845 TRANSFORMER PROTECTION SYSTEM – INSTRUCTION MANUAL
CURRENTS CHAPTER 6: METERING
Currents
NOTE
NOTE:
The number of Currents supported is order code dependent.
Path: Metering > Currents
Phase A (Ia) 0.000 A
Range: 0.000 to 12000.000 A
Phase B (Ib)
Range: 0.000 to 12000.000 A
Phase C (Ic)
Range: 0.000 to 12000.000 A
Ground (Ig)
Range: 0.000 to 12000.000 A
Sensitive Ground (Isg)
Range: 0.000 to 1200.000 A
Neutral (In)
Range: 0.000 to 12000.000 A
Phase A (Ia RMS)
Range: 0.000 to 12000.000 A
Phase B (Ib RMS)
Range: 0.000 to 12000.000 A
Phase C (Ic RMS)
Range: 0.000 to 12000.000 A
Ground (Ig RMS)
Range: 0.000 to 12000.000 A
Sensitive Ground (Isg RMS)
Range: 0.000 to 1200.000 A
Neutral (In RMS)
Range: 0.000 to 12000.000 A
Phase A Angle (Ia Angle)
Range: 0.0 to 359.9°
Phase B Angle (Ib Angle)
Range: 0.0 to 359.9°
Phase C Angle (Ic Angle)
Range: 0.0 to 359.9°
Ground Angle (Ig Angle)
Range: 0.0 to 359.9°
Sensitive Ground Angle (Isg Angle)
Range: 0.0 to 359.9°
Neutral Angle (In Angle)
Range: 0.0 to 359.9°
Average (I AVG)
Range: 0.000 to 12000.000 A
