6–12 845 TRANSFORMER PROTECTION SYSTEM – INSTRUCTION MANUAL
VOLTS PER HERTZ CHAPTER 6: METERING
Volts Per Hertz
Path: Metering > Volts per Hertz
VOLTS PER HERTZ 1 (2)
Range: 0.00 to 4.00 V/Hz in steps of 0.01
Default: 0.00 V/Hz
Harmonic Magnitude
Path: Metering > Harmonic I Magnitude
J1 Phase A 2nd Harm Mag
Range: 0.000 to 4294967.295 in steps of 0.001
J1 Phase B 2nd Harm Mag
Range: 0.000 to 4294967.295 in steps of 0.001
J1 Phase C 2nd Harm Mag
Range: 0.000 to 4294967.295 in steps of 0.001
J1 Phase A 5th Harm Mag
Range: 0.000 to 4294967.295 in steps of 0.001
J1 Phase B 5th Harm Mag
Range: 0.000 to 4294967.295 in steps of 0.001
J1 Phase C 5th Harm Mag
Range: 0.000 to 4294967.295 in steps of 0.001
K1 Phase A 2nd Harm Mag
Range: 0.000 to 4294967.295 in steps of 0.001
K1 Phase B 2nd Harm Mag
Range: 0.000 to 4294967.295 in steps of 0.001
K1 Phase C 2nd Harm Mag
Range: 0.000 to 4294967.295 in steps of 0.001
K1 Phase A 5th Harm Mag
Range: 0.000 to 4294967.295 in steps of 0.001
K1 Phase B 5th Harm Mag
Range: 0.000 to 4294967.295 in steps of 0.001
K1 Phase C 5th Harm Mag
Range: 0.000 to 4294967.295 in steps of 0.001
K2 Phase A 2nd Harm Mag
Range: 0.000 to 4294967.295 in steps of 0.001
K2 Phase B 2nd Harm Mag
Range: 0.000 to 4294967.295 in steps of 0.001
K2 Phase C 2nd Harm Mag
Range: 0.000 to 4294967.295 in steps of 0.001
K2 Phase A 5th Harm Mag
Range: 0.000 to 4294967.295 in steps of 0.001
