6–20 845 TRANSFORMER PROTECTION SYSTEM – INSTRUCTION MANUAL
RTDS CHAPTER 6: METERING
RTDs
Path: Metering > RTDs
NOTE:
The Temperature can be displayed in Celsius or Fahrenheit degrees. The selection is made
in Setpoints > Device > Installation > Temperature Display.
RTD 1(13)
Range: -40 to 250°C (temperatures < -40°C are displayed as “Shorted” and temperatures >
250°C are displayed as “Open RTD”)
RTD Maximums
Path: Metering > RTD Maximums
NOTE:
The Temperature can be displayed in Celsius or Fahrenheit degrees. The selection is made
in Setpoints > Device > Installation > Temperature Display.
Reset RTD Date/Time
Range: DD/MM/YY hh/mm/ss
NOTE:
Maximum RTD values can be cleared (reset) by setting the value of Setpoints > Records >
Clear Records > RTD Maximums to “ON”. Executing this command loads -40°C as the initial
Maximum RTD value.
RTD 1(13) Max
Range: -40 to 250°C (temperatures < -40°C are displayed as “Shorted” and temperatures >
250°C are displayed as “Open RTD”)
RTD 1(13) Max Date/Time
Range: DD/MM/YY hh/mm/ss
Analog Inputs
Path: Metering > Analog Inputs
Analog Ip 1 (4)
Range: -500000 to 500000 units in steps of 1
