6–10 845 TRANSFORMER PROTECTION SYSTEM – INSTRUCTION MANUAL
VOLTAGES CHAPTER 6: METERING
Voltages
NOTE
NOTE:
The number of Voltages supported is order code dependant.
Path: Metering > Voltages
Phase A (Van)
Range: 0.00 to 600000.00 V
Phase B (Vbn)
Range: 0.00 to 600000.00 V
Phase C (Vcn)
Range: 0.00 to 600000.00 V
Phase to Phase AB (Vab)
Range: 0.00 to 600000.00 V
Phase to Phase BC (Vbc)
Range: 0.00 to 600000.00 V
Phase to Phase CA (Vca)
Range: 0.00 to 600000.00 V
Neutral (Vn)
Range: 0.00 to 600000.00 V
Auxiliary (Vaux)
Range: 0.00 to 600000.00 V
Phase A (Van RMS) 0.00 V
Range: 0.00 to 600000.00 V
Phase B (Vbn RMS)
Range: 0.00 to 600000.00 V
Phase C (Vcn RMS)
Range: 0.00 to 600000.00 V
Phase to Phase AB (Vab RMS)
Range: 0.00 to 600000.00 V
Phase to Phase BC (Vbc RMS)
Range: 0.00 to 600000.00 V
Phase to Phase CA (Vca RMS)
Range: 0.00 to 600000.00 V
Neutral (Vn RMS)
Range: 0.00 to 600000.00 V
Auxiliary (Vaux RMS)
Range: 0.00 to 600000.00 V
Phase A Angle (Van Angle)
Range: 0.0 to 359.9°
Phase B Angle (Vbn Angle)
Range: 0.0 to 359.9°
Phase C Angle (Vcn Angle)
Range: 0.0 to 359.9°
