Replaceable parts
NOTE
The ApexPro CH transmitter has no internal field-replaceable parts.
T14 transmitter parts list
This list is for CARESCAPE telemetry T14 transmitter at 1395.025 - 1399.975 MHz.
NOTE
The T14 transmitter has no internal field-replaceable parts.
Receiver subsystem disassembly guidelines
General
WARNING
PATIENT MONITORING INTERRUPTION—Make sure a patient
is not being monitored.
When removing the receiver subsystem pcb, use the following tools:
3-4 inch Phillips head screwdriver
12 inch Phillips head screwdriver
1/2 inch crescent wrench
PCB assemblies
CAUTION
Solder multilayer and surface mount PCB assemblies at your own
risk! Improper repair methods can damage the PCB assemblies even
further and void the warranty. Only qualified service personnel with
the proper laboratory equipment should attempt to repair PCB
assemblies.
Part number Description
APRO-CH-US-ENG-AHA-4 Transmitter - ApexPro CH
2017569-009 Dust covers (kit)
Part number Description
TLMTX-T14-ENG-CAAXXX Transmitter - CARESCAPE T14
2017569-009 Dust covers (kit)
