Technical specifications
2001989-351A ApexPro™ A-13
Transport and storage conditions
Physical specifications
Subsystem
Certification
Receiver Unit
420-474 MHz – R&TTE
560 – 614 MHz – FCC Part 15, Subpart B Class B (U.S. only)
Subsystem
UL 60601-1 Classified. IEC 60601-1 and IEC 60601-1-2 Certified. CE marked per
the Medical Devices Directive 93/42/EEC. Yakuji (Japanese Ministry of Health,
Labour and Welfare).
Antenna specifications
Performance specifications
Temperature –40°C to 70°C (–40°F to 158°F)
Relative humidity 15% to 95% (non condensing)
Height 170 mm (6.7 in)
Width 325 mm (12.8 in)
Depth 250 mm (9.8 in)
Weight 6.4 kg (14 lb) with 4 quad receiver modules
Type
Hi-Pwr
(-002, -004)
Passive
(-003, -005, -006)
Active
(-007)
Active
(-008)
Voltage range 7.0 – 12.6 V N/A 8.0 - 12.6 V 8.0 - 12.6 V
Minimum voltage 7.0 V N/A 8.0 V 8.0 V
Current draw 55 mA N/A 115 mA 52 mA
Gain 17 dB –5dB 28.5 dB 15 dB
