Technical specifications
2001989-351A ApexPro™ A-7
Physical specifications
FCC compliance information
This device complies with Part 95 of the FCC Rules.
Operation of this equipment requires the prior coordination with a frequency
coordinator designated by the FCC for the Wireless Medical Telemetry Service.
Certifications
UL/IEC/EN 60601-1
IEC/EN 60601-1-1
IEC/EN 60601-1-2
IEC/EN 60601-1-4
IEC/EN 60601-2-27
IEC/EN 60601-2-49
1395.025 to 1399.975 MHz - FCC Part 95
Graph request Transmitted
Event Marker Transmitted
Maximum transmitters 199 active within WTMS at a single facility
Dynamic range ± 5 mV (RTI)
Input offset ± 300 mV (RTI)
Input impedance 15 M ohm minimum differential @ 10 Hz
ECG gain selection 5, 10, 20, 40 mm/mV (RTI)
ECG gain accuracy ± 5% @ 15 Hz
Common mode rejection 100 dB minimum @ 60 Hz
Defibrillator protection ± 5000 VDC, 360 joules into 100 ohm
Defibrillator recovery time Transmitter recovers within 5 seconds
Pacemaker detection ± 2 mV to ± 700 mV (RTI); 100 µsec to 2 msec; either
polarity; on multiple leads
Patient leakage current Meets UL/IEC 60601-1
Serial communications 2 ports at 9600 baud asynchronous
Height 13.7 cm (5.38 in)
Width 7.3 cm (2.875 in)
Depth 2.3 cm (0.91 in)
Weight 141.8 g (0.275 lb) without battery; 170.1 g (0.375 lb) with
battery
