Printing Data 4-3
March 2008
Print Live Data Use the DATA submenu to print live measurement data as it is
collected. The data may be printed in either numeric or graphical
format, with a user specified time increment.
IMPORTANT: Make sure that a printer has been properly set up
before proceeding with this section.
To print live measurement data, refer to Figure A-7 on page A-7, and
complete the following steps:
1. To access the Print Menu, press the
[PRNT] key.
Note: The Print Menu is not
protected by the security feature and a
password is never required to access this menu.
2. Press
[F1] = DATA.
3. Press
[F1] to print the data in numeric format or press [F2] to print
the data in graphical format.
• If you press [F1], go to step 4.
• If you press [F2], go to step 8.
Numeric Format 4. Use the [←], [→] and [F1]-[F4] keys to select the first parameter to
be printed. See Table 4-2 below for a list of the available options.
Table 4-2: Measurement Parameter Options
Option Bar Choice Description
[F1] = VEL Flow Velocity
[F2] = VOLUM Volumetric Flow
[F3] = +TOTL Forward Totalized Volume Flow
[F4] = -TOTL Reverse Totalized Volume Flow
[→] + [F1] = MDOT* Mass Flow
[→] + [F2] = +MASS* Forward Totalized Mass Flow
[→] + [F3] = -MASS* Reverse Totalized Mass Flow
[→] + [F4] = POWER** Energy Flow Power
[→] + [→] + [F1] = +ENRG** Forward Energy Flow
[→] + [→] + [F2] = -ENRG** Reverse Energy Flow
[→] + [→] + [F3] = DIAG Diagnostic
* Available only if “Mass Flow (static)?” = YES
**Available only if “Energy Option” = YES
