March 2008
4-8 Printing Data
Print Site File Use the PROG submenu to print the data in a site file that was set up
and saved as described in Chapter 1, Programming Site Data. To print
a site file, refer to Figure A-7 on page A-7, and complete the
following steps:
IMPORTANT: Make sure that a printer has been properly set up
before proceeding with this section.
1. To access the Print Menu, press the
[PRNT] key.
Note: The Print Menu is not
protected by the security feature and a
password is never required to access this menu.
2. Press
[F3] = PROG.
3. Use the [←], [→] and
[F1]-[F4] keys to select the desired Site File
to print.
Note: All site files currently in memory appear on the option bar.
The currently active site file (or working file) is always listed
as the first choice
(Work) on the option bar.
The Model DF868 returns to the standard data display screen and
generates a site file printout similar to the one shown in Figure 4-5
below. The printout continues until the entire file has been printed or
until a
STOP command is issued (see the instructions for the STOP
submenu on page 4-9).
Figure 4-5: A Typical Site File Printout
Mass Flow Units
Pipe OD
.
Pipe Wall
Path Length
Axial Dimension L
PIPE PARAMETERS:
Transducer number
Mass Decimal Digits
.
.
Mass Units
CHAN SYSTEM PARAMETERS
Equation
Ch1 Channel LABEL Channel MESSAGE
CHAN ACTIVE PARAMETERS
Site status
Skan/measure mode
Burst
Skan Only
Standard Equation
Thousands ACF
/min
0
Pounds
0
81
12.000 inches
0.200 inches
16.97 inches
12.00 inches
.
.
.
At 9:54:39 AM on 11 FEB 99
With 1K FIFO and 1113 receiver board
Model GX868G3G
PROGRAM PARAMETERS of SITE NAME
Mass Flow Time
MDOT Decimal Digits
Volumetric Units
Volumetric Time
VOL Decimal Digits
Totalizer Units
TOT Decimal Digits 0
Actual cubic ft
Pounds
/sec
0
To Next Page
