Displaying Data 2-3
March 2008
The BIG Submenu (cont.)
Note: See Chapter 3, Operation, of the Startup Guide for more
details on selecting a measurement parameter to display.
The DUAL Submenu The DUAL format displays two measurements simultaneously in
normal print. To select the
DUAL format and the measurements to
display in this format, follow the instructions in this section.
Upon power up, a standard measurement mode display (similar to the
one shown below) appears in
BIG format. Press the appropriate side of
the
[SCREEN] key to activate the desired pane of the display screen,
and complete the following steps:
1. To access the Display Menu, press the
[DISP] key.
2. Press
[F2] = DUAL. The measurement mode display reappears and
the display is now in the
DUAL format.
3. Use the
[F1]-[F4], [←] and [→] keys to select the desired display
parameter option. See Table 2-1 above for a complete description
of the available options.
With the
DUAL format display screen active, when a measurement
parameter is selected, the top line of the prompt area will be changed
to show that parameter. The parameter previously displayed at the top
of the display is moved to the bottom of the display, and the previous
bottom parameter is no longer shown.
Table 2-1: Measurement Parameter Options
Option Bar Choice Description
[F1] = VEL Flow Velocity
[F2] = VOLUM Volumetric Flow
[F3] = +TOTL Forward Totalized Volume Flow
[F4] = -TOTL Reverse Totalized Volume Flow
[→] + [F1] = TIME Total Flow Measurement Time
[→] + [F2] = MDOT* Mass Flow
[→] + [F3] = +MASS* Forward Totalized Mass Flow
[→] + [F4] = -MASS* Reverse Totalized Mass Flow
[→] + [→] + [F1] = POWER** Energy Flow Power
[→] + [→] + [F2] = +ENRG** Forward Energy Flow
[→] + [→] + [F3] = -ENRG** Reverse Energy Flow
[→] + [→] + [F4] = DIAG Diagnostic
* Available only if “Mass Flow (static)?” = YES
**Available only if “Energy Option” = YES
