Printing Data 4-7
March 2008
Numeric Format After the numeric format (and starting page and number of pages, if
applicable) is chosen, the Model DF868 returns to the standard data
display screen and begins printing the log file. The printout continues
until the entire log has been printed or until a
STOP command is issued
(see the instructions for the
STOP submenu on page 4-9). A portion of
a typical printout is shown in Figure 4-3 below.
Figure 4-3: A Typical Numeric Printout
Graphical Format After the graphical format (and starting page and number of pages, if
applicable) is chosen, the following additional prompts must be
answered:
7. Enter the desired maximum value for the Y (vertical) axis and
press
[ENT].
Note: Enter a
Y AXIS MAX value that is larger than the largest logged
measurement value.
8. At the Y Range prompt, press
[F1] to show only the positive Y axis
or press
[F2] to display both the positive and negative y axis.
The Model DF868 returns to the standard data display screen and
begins printing the log file. The printout continues until the entire log
has been printed or until a
STOP command is issued (see the
instructions for the
STOP submenu on page 4-9). A portion of a typical
printout is shown in Figure 4-4 below.
Figure 4-4: A Typical Graphical Log Printout
Start Time
End Date
End Time
HH:MM:SS
11:50:45 A
11:50:55 A
11:51:05 A
11:51:15 A
11:51:25 A
11:51:35 A
11:51:45 A
11:51:55 A
11:52:05 A
11:52:15 A
.
.
.
ACF/HR
686.85
684.00
678.12
680.58
.
.
670.70
675.99
669.79
675.59
662.28
666.71
.
VOLUM
232.57
236.34
234.46
.
.
.
ACF
230.45
228.58
226.71
224.84
222.70
220.83
218.92
+TOTL
1039.082
.
.
1038.860
1039.255
.
FT/S
1039.511
1039.105
1039.137
1039.470
1039.509
1039.003
1039.147
SNDSP
Start Date
LOG MESSAGE
LOG NAME Page# 1
LOG DUMP
09 SEP 97
11:50:43 AM
09 SEP 97
11:54:45 PM
Ch1 Ch1 Ch2
0.0
.1
.2
.3
.4
.5
.6
.7
.8
.9
1.0
0.0
.1
.2
.4
.3
.5
.7
.6
.8
.9
1.0
CHANNEL NAME
CHANNEL MESSAGE
X-AXIS 50 seconds PER-DIV
Y-AXIS MAX 500 ACF/M
START TIME
03:27:01 PM
20 OCT 97
END TIME
03:28:46 PM
20 OCT 97
