March 2008
C-6 Programming with PanaView
Adding the DF868 (cont.) IMPORTANT: The Network ID number must match the Network ID
programmed in the meter’s Communications menu.
If the initialization is successful, the Meter Browser shows a listing
similar to Figure C-6 below.
Figure C-6: Updated Network Tree
Note: The model number and version that appear will vary with
your particular meter and software version.
However, if the settings do not match, or there is some other
difficulty, a screen appears similar to Figure C-7 below.
Figure C-7: Communication Error Screen
The screen offers the options of trying again or of canceling the
operation. Click on the desired choice, and then on
[OK] to confirm the
choice or on
[Exit Application] to close PanaView.
Note: If you cannot resolve the problem, contact the factory for help.
