GE LOGIQ P3 EXPERT User Manual

GE PROPRIETARY TO GE
D
IRECTION 5308917-100, REVISION 8 LOGIQ P3 SERVICE MANUAL
8-6 Section 8-2 - Disassembly/Re-assembly of LOGIQ P3
Figure 8-4 Power cable & DVI cable (LOGIQ P3 BT10)
8) Disconnect the power cable & DVI cable from the LCD monitor system.Refer Figure 8-5 on page 8-6
Figure 8-5 Remove Power cable & DVI cable
DVI cable
power cable

GE LOGIQ P3 EXPERT Specifications

General

Brand	GE
Model	LOGIQ P3 EXPERT
Category	Medical Equipment
Language	English
