NX-10 Installers manual
105
Data Event Data Event
1 Fire alarm 31 Closed period
2 24 hour alarm 32 Listen-in
3 Trouble alarm 33 Line seizure
4 Tamper alarm 34 Reserved
5 Yelping siren 35 Fail to communicate
6 Steady siren 36 Telephone line fault
7 Any siren 37 Program mode
8 Any bypass 38 Download in process
9 AC fail 39 Reserved
10 Low battery 40 Short circuit (overcurrent on 12 V DC)
11 Duress 41 Box tamper
12 Aux 1 keypad (fire alarm) 42 Siren tamper
13 Aux 2 keypad (medical alarm) 43 Any open
14 Panic keypad 44 Any short
15 Keypad tamper 45 Any fault (open/short on non-fire zone)
16 Autotest 46 Any alarm
17 Alarm memory (solid) 47 Beeping keypad
18 Entry
48♦
Code entry (see note below)
19 Exit
49♣
Key FOB function 1
20 Entry or exit
50♣
Key FOB function 2
21 Armed state 51 Always ON
22 Disarmed state 52 Autoarm warning time
23 Ready 53 Any siren when in away mode
24 Not ready 54 Progress of entry/exit (follows keypad
buzzer)
25 Fire 55 Auxiliary communication failure
26 Fire trouble 56 Radio test
27 Chime 57 Any siren when armed in any mode
28 Expander trouble 58 Alarm memory (pulsating)
29 Dynamic battery test time 59 Zone inactivity
Notes:
♦
When event 48 is programmed, it is possible to program a user code authorisation to select the
output(s), which a particular code will activate.
♣
Events 49 and 50 require one or more of the following to operate: wireless receivers or
cardreaders.
If set to follow condition, these events will be 1 second.
Setup for auto-test, auto-arm and opening/closing times
LOCATION 51 - AUTOTEST CONTROL (4 segments, numerical data)
Segment 1
Program a “1” if the interval is to be in hours; program a “0” for days. Add a “2” to
suppress the daily test or a “3” to suppress the hourly test if any report has been
sent
Segment 2
Program the autotest interval from 1-255 hours/days
Segment 3
Program the autotest report hour in 24 hour format (if the interval is in hours, this
segment Is ignored)
Segment 4
Program the autotest report time, number of minutes after the hour
