NX-10 Installers man
ual
249
NX-1701E door swipe modules
Table 41. NX-1701E
module numbers
Learn-in sequen
ce
Module number
Learn-
in sequence
Module number
1 113
9
121
2 114
10
122
3 115
11
123
4 116
12
124
5 117
13
125
6 118
14
126
7 119
15
127
8 120
Keypads
Table 42.
Keypad modul
e numbers
Keypad
Partition 1
Partition 2
Partition 3
Partition 4
1
192 193 194 195
2
200 201 202 203
3
208 209 210 211
4
216 217 218 219
5
224 225 226 227
6
232 233 234 235
7
240 241 242 243
8
248 249 250 251
248
250
Table of Contents
Default Chapter
3
Table of Contents
3
NX-10 Installers Manual
3
Preface
9
Safety Terms and Symbols
9
References
9
Section a Installing and Programming a Basic System
10
Chapter A1 Introducing the NX-10 System
11
NX-10 Diagram
11
NX-10 Technical Specifications
13
NX-10 System
14
Parts of the System
14
Keypads
18
Wireless Keypad
18
LCD Icons
21
Chapter A2 Installation Guidelines
23
Mains Power Connection
23
Mounting
23
Wiring Guidelines
23
Defaulting the Panel
24
Chapter A3 Installing a Basic System
25
Installing the NX-10
25
Small Polycarbonate Housing
25
Installing the Keypad
26
Mounting the Wireless Keypad
26
Mounting the Wired Keypad
27
Keypad Learning-In Procedure
28
Installing the Wireless Sirens
29
Installing the Wireless Sensors
35
Mounting the Sensors
35
Sensor Learning-In Procedure
35
Chapter A4 Programming Guidelines
36
Getting Started
36
Country Codes
36
Powering up the System
37
Entering Programming Mode
37
Changing the User Interface Language
37
Navigating the Menus
38
Quick User Menu
38
Selecting a Menu Option
38
Changing a Menu Option
38
Changing Selection List Entries
38
Changing Binary Entries
39
Changing Numeric Entries
39
Changing Phone Numbers and Phone Prefixes
39
Exiting the Menu System
40
Editing Text
40
Overview
40
Example
41
Word Library
41
Guidelines for Location-Based Programming
42
Selecting the Module to Program
42
Programming a Location
42
Exiting the Program Mode
43
Chapter A5 Setting up a Communicator
44
Reporting
44
Reporting to One Phone Number
44
Backup Reporting
44
Dual Reporting
45
Split Reporting
46
Section B Programming the System
46
Chapter B1 Selecting the Programming Mode
47
Chapter B2 Programming the Control Panel
48
Overview
48
Programming Inputs
48
Defining a Zone
50
Copying Zone Settings
51
Editing a Zone Type
51
Setting Swinger Count
52
Programming Outputs
52
Configuring an Output
53
Configuring the Internal Siren
54
Programming the Keypad Sounder
54
Assigning Codes
54
Setting up the Installer Code
55
Setting Communication Options
56
Defining Communication with a Central Station
57
Defining Communication with Upload/Download Software
58
Configuring the System Autotest
58
Enabling Reporting
59
Configuring Partitions
60
Setting Timers
60
Configuring a Partition
60
Configuring the System
61
Setting Timers
62
Configuring System Features
62
Setting Arm Schedules
63
Setting up Schedules
63
Glossary
64
Control Panel Programming Locations
86
Telephone Number 1
86
Reporting Events to Phone Number 1
87
Telephone Number 2
88
Reporting Events to Phone Number 2
90
Telephone Number 3
91
Reporting Events to Phone Number 3
92
Special Formats
93
Download Parameters
93
Feature and Report Selections (for Partition 1)
94
Entry/Exit Timers
95
Zone Configurations and Partition Selection
96
General Options
100
Programming the Outputs
104
Setup for Auto-Test, Auto-Arm and Opening/Closing Times
105
Communicator Codes for Slow Speed Formats Only
107
Programming Partition Parameters
114
Programming Zone Configuration Groups
116
NX-10 Location-Programming Worksheets
130
Chapter B3 Programming the NX-1048 Keypad
143
Overview
143
Configuring the NX-1048 Keypad Features
145
General Options
145
Programming the Function Keys
145
Setting up the Tamper Switch
147
Battery Replacement
148
Master Mode
151
Assigning X-10 Devices
151
Copying Keypad Settings
151
Configuring Keypad Text
152
Setting Installer Messages
152
Setting the Keypad Partition and Keypad Number
153
Setting the Exit Buzzer Options
153
Glossary
154
Technical Specifications
159
Chapter B4 Programming the Other Keypads
161
Chapter B5 Setting up the RF Receivers
161
Programming the RF System
162
Setting up the Rf Receivers
162
Defaulting the Wireless Modules
163
Programming the Wireless Detectors
163
Learning-In Additional Wireless Keypads
164
Deleting Wireless Keypads
165
Learning-In IO Modules
166
Learning-In Wireless Sirens
166
Configuring IO Modules
167
Configuring Receiver Features
167
Setting Supervision Windows
170
Testing Wireless Sensors
170
Disabling Wireless Sensors
171
Glossary
171
Programming Locations for the RF Receivers
176
Chapter B6 Setting up the GSM/GPRS Module (NX-7002)
180
Overview
180
Enrolling the GSM/GPRS Module
180
Enrolling the SIM Card on the GSM Network
181
Enrolling the SIM Card on the GPRS Network
181
Inserting a SIM Card
182
Testing the RSSI Value
183
Testing the GSM or GPRS Connection
183
Programming the GSM/GPRS Module (NX-7002)
185
Programmable Options
186
Reporting
186
Overview
186
Report Methods
188
Report Controllers
188
Primary and Secondary Reporting
188
GSM/GPRS Module as Backup (SMS / GPRS)
189
GSM/GPRS Module as Backup (Audio Reporting)
189
Setting up Polling
191
Upload/Download
191
Reporting Summary
192
Using the GSM/GPRS Module
196
Obtaining the GSM/GPRS Module Status
196
Troubleshooting
197
Autotest
197
Reporting Protocols and Formats
197
Reporting Fixed Codes in SIA and Contact ID
197
Special Reports
199
SMS SIA Reporting Message Format
199
SMS Contact ID Reporting
201
Hometext Control
201
Receiving SMS Messages from a Security System
204
Hometext Reporting
204
Glossary
205
GSM/GPRS Module Location-Based Programming Worksheets
213
Chapter B7 Enrolling Modules
223
Enrolling the System Modules
223
Defaulting the Modules
223
Glossary
224
Chapter B8 Reading the Event Log
225
Overview
225
Event Log Events
226
Glossary
230
Chapter B9 NX-586E
231
Overview
231
Connecting the NX-586E Direct Connect Module
231
Connecting the NX-586E to a PC
231
Connecting the NX-586E to a PC and a Panel
232
Connecting the NX-586E to a Panel
233
Programming the NX-586E Direct Connect Module
233
Enabling Memory Transfer Using the Keypad
233
Panel to PC Memory Transfer Using DL900 Software
234
Writing Data from the DL900 Software to the NX-586E
234
Reading Data from the NX-586E to the DL900 Software
234
Location Programming for the NX-586E
235
Glossary
235
Technical Specifications
236
Chapter B10 Programming with the DL900 Software
237
Other Methods of Programming
237
Connecting the Panel to the Computer
237
Connecting Using a Serial Port
237
Connecting Using a Modem
238
Programming with Upload/Download Software
238
Programming Tasks
239
Chapter B11 Updating Firmware
242
Overview
242
Update Procedure
242
Section C References
244
Appendix 1: Reporting Fixed Codes in Contact ID or SIA
245
Appendix 2: Overview of Module Numbers
248
NX-1701E Door Swipe Modules
249
Keypads
249
Appendix 3: Communicator Formats
250
Appendix 4: Service Messages
251
Appendix 5: Tasks Summary
253
Appendix 6: Word Library
254
Index
255
