Term Definition
option is set to Disabled, keypads do not wake up, and chime is not emitted.
Please note, that also other keypad settings can affect whether the acoustic
signal is actually emitted or not, for example, Keypad Features>Silent Keypad.
X-10 Address A menu entry that groups X-10 configuration options for IO modules.
Zone/User Selects the zone or user number necessary to trigger an output. If this location
is programmed as a zero (“0”), any zone or user will activate the output (see
also location 68).
The zone/user filter is active only for following events: Burglary Alarm, Fire
Alarm, 24h Alarm, Zone Tamper (it filters out zones for all these events), and
Code Entry (it filters out users). For all other events this setting is ignored.
Programming locations for the RF receivers
In the Table 19 you can find list of locations related to the output events. Please note, that
descriptions for locations 70, 71 and 72 given below for the output 1, pertain also to the respective
locations for the outputs 2 to 8.
Table 19. RF receiver location map – locations related to output events.
Output Location Segment Type Description IO module
1 dec value Event number
2 dec value Zone / user number
70
3 dec value Time
1 option Special configuration
71
2 option Partition
1 hex value X-10 unit code
1
72
2 hex value X-10 house code
1 dec value Event number
2 dec value Zone / user number
73
3 dec value Time
1 option Special configuration
74
2 option Partition
1 hex value X-10 unit code
2
75
2 hex value X-10 house code
IO module 1
1 dec value Event number
2 dec value Zone / user number
76
3 dec value Time
1 option Special configuration
77
2 option Partition
1 hex value X-10 unit code
3
78
2 hex value X-10 house code
1 dec value Event number
2 dec value Zone / user number
79
3 dec value Time
4
80 1 option Special configuration
IO module 2
