GIRBAU LOGI CONTROL User Manual

Maintenance 77
Cod. 523340
Rev. 10/1016
10.3. Cleaning the solenoid valve filters
Only by qualified personnel
Required tools:
 Disassembly of the fittings: Slip-joint pliers or pipe spanner diam. 1-½ in. (35 mm)
 Disassembly of the filter supports: spanner 1-
3
/
8
in (34 mm)
 Disassembly of the filters: pliers
Steps to follow
 Disconnect and mechanically lock the external switch. Close and mechanically interlock the manual water
supply valves.
 To avoid the risk of burns, check the temperature of the hot water inlet hose.
 Disassemble the fittings that connect the hoses to the washing machine.
 Disassemble the filter supports (according to model).
 Remove the filters from their housings and clean the filters with pressurised water. Refit them in their
housings.
 Assemble the solenoid valve supports (according to model).
 Assemble the hoses in their corresponding inputs. Tighten the fittings.
 Connect the external switch, open the manual water input valves and check the water-tightness of the
coupling.
10.4. Checking safety mechanisms
10.4.1. Checking the door lock
Check the door safety lock device on a DAILY basis.
CAUTION. Only by qualified personnel
Take great care in checking the safety mechanisms.
Carry out the check described below while the drum is turning at washing speed and never at a higher
speed.
If there is a failure in the door lock, never place one’s hand in the loading area of the washer.
Checking procedure:
Disconnect the ON switch. The display is off.
Close and mechanically interlock the manual water supply valves (and steam inlet valve in washers with this
option included).
Open the washing machine door.
Connect the ON/OFF switch. The display will read door.
Close the door.
Select and start a wash cycle.
About a minute after starting the cycle, check that the door is locked.
Press the START/STOP key to finish the check.
After a safety period of no longer than 30 seconds has passed, the door lock will be released.
The check is completed.
If no anomaly has been detected, open the fluid inlet valves.
CAUTION
If anything other than that was described is detected during the operation, disconnect the washer, do not
use it, and contact the Authorised Technical Service URGENTLY.
