ASSIGN
This function sets the destination for the transferred data.
Applications:
• Transferring values with Q parameter function FN15
• Transferring values with Q parameter function FN16
• Path on the TNC’s hard disk in which the digitized data are stored
The TNC mode of operation determines whether the PRINT or
PRINT TEST function is used:
TNC mode of operation Transfer function
Program Run, Single Block PRINT
Program Run, Full Sequence PRINT
Test run PRINT TEST
You can set PRINT and PRINT TEST as follows:
Function Path
Output data via RS-232 RS232:\....
Output data via RS-422 RS422:\....
Save data to the TNC’s hard disk TNC:\....
Save data in directory in which the program
with FN15/FN16 or the program with the
digitizing cycles is located - vacant -
File names
Data Operating mode File name
Digitizing data Program Run Defined in the RANGE
cycle
Values with FN15 Program Run %FN15RUN.A
Values with FN15 Test run %FN15SIM.A
Values with FN16 Program Run %FN16RUN.A
Values with FN16 Test run %FN16SIM.A
12.4 Setting the Data Interfaces
