15HEIDENHAIN TNC 426 B, TNC 430
2.2 Moving the Machine Axes
Traversing with the machine axis direction buttons is a
machine-dependent function. Refer to your machine tool
manual.
To traverse with the machine axis direction buttons:
Select the Manual Operation mode.
<
Press the machine axis direction button and
hold it as long as you wish the axis to move.
...or move the axis continuously:
and Press and hold the machine axis direction
button, then press the machine START button:
The axis continues to move after you release
the keys.
To stop the axis, press the machine STOP
button.
You can move several axes at a time with these two methods. You
can change the feed rate at which the axes are traversed with the F
soft key (see „2.3 Spindle Speed S, Feed Rate F and Miscellaneous
Functions M).
2.2 Moving the Machine Axes
