User Manual of Digital Video Recorder
62
4.2.6 Calling Patterns
Purpose:
The PTZ camera will move according to the predefined pattern path when you call a pattern.
Call a pattern in the PTZ setting interface
Steps:
1. Enter the PTZ Control interface.
Menu> Camera> PTZ> More Settings
2. Select the pattern number.
3. Click , then the PTZ moves according to the pattern. Click to stop it.
Figure 4. 12 PTZ- Calling Pattern
Call a pattern in live view mode.
Steps:
1. Open the PTZ control panel in live view mode.
2. Click the Camera tab on the panel, and select the channel for control on the camera list.
3. Click the Pattern tab on the panel, and then double-click the pattern, or click to select the patrol and click
to call the pattern.
Figure 4. 13 PTZ Panel- Pattern
