User Manual of Digital Video Recorder
66
Sensor alarm is not supported by DS-7200HWI-SV series. The interfaces of the device are subject to the actual
model.
5.1 Configuring Encoding Parameters
Purpose:
By configuring the encoding parameters you can define the parameters which affect the image quality, such as
transmission stream type, the resolution, etc.
Before you start:
1. Make sure that the HDD has already been installed. If not, please install a HDD and click Init to initialize
it. (Menu > HDD > General)
Figure 5. 1 HDD- General
2. Check the storage mode of the HDD
1) Click Advanced to check the storage mode of the HDD.
2) If the HDD mode is Quota, please set the maximum record capacity and maximum picture capacity.
For detailed information, see Chapter 11.5 Configuring Quota Mode.
3) If the HDD mode is Group, you should set the HDD group. For detailed information, see Chapter
5.8 Configuring HDD Group for Recording and Capture.
Steps:
1. Enter the Record settings interface to configure the encoding parameters:
Menu > Record > Parameters
Figure 5. 2 Record Parameters
