2.2 DIMENSIONAL DATA
2.3 SPECIFICATION
HYJM-S01H Model
0.68Kg(Approx.)
Indoor
Wall Built-in or Wall Surface Mounting
160 (Max.)
± 70 Seconds/Month (at Normal Temperature)
5~35 ȭ
35
~
90% (No Dew Condensation)
7” TFT Color Liquid Crystal Display (1024 x 600 dots)
1
Őˈ
AC 100
240V
ˈ
50/60Hz
220x148x20+33(mm)Outer Dimension <W x H x D + (Built-in Part)>
Net Weight
Installation Location
Installation Method
Connected Indoor Unit (Qty)
Clock Accuracy
Ambient temperature
Ambient Humidity
Display
Rated Power Supply
Electrical Power Consumption 13.5W (Max.)
220
168
165
AC 100 ~240V input RS-485(Reserve) LAN(Reserve)
For external output For external input H-NET
80
148
96
Unit:mm
53
33 20
Press inside button with
a needle to reboot
controller
HYJM-S01H
To Next Page
