Installation & Operation Manual for Wireless Remote Control
HY(-W01
To ensure correct use of this remote control, please read this manual carefully before use.
This manual should be read along with the installation manual for
air conditioner.
Discrepancy of display will occur when:
1)
<ou press Sleep button while sleep function is unavailable in your indoor unit;
2)
You press (&2 button while power saving function is unavailable in \RXULQGRRU unit;
3)
You press Mute button while power mute function is unavailable in your LQGRRU unit;
4)You press SH button while strong heating function is unavailable in\RXULQGRRU unit;
Discrepancy of display may occur when:
1)<ou press 3D/S button while 3D/strong airflow function is unavailable in your indoor unit;
2)
You press Hor.EXWWRQwhile horizontal a irflow function is unavailable in your indoor unit;
Discrepancy of display may occur when lower temperature limit is set when this remote control
is used along with wired remote control with receiver due to difference in indoor units.
Check the box after checking related items as shown below.
1. Before Installation
1)
The following parts are part of the wireless Remote Control,please check them.
Name Quantit\ Use
Wireless remote control
1
For control of operation
No.7 battery
2
For power supply to remote control
Remote control holder
1
For fixing of remote control
Screw (M4×16)
For fixing of remote control holder
2. Mounting of Battery
1) Mount two No.7 batteries into the battery container in remote control.
(1) Pulling out the container cover.
(2) Mount battery in.
Pay attention to poles of batteries when mounting them!
3. Operation Instructions
1)
Remove the batteries if the remote control is left idle for a long period.
2) Replace the batteries in pair.
3) After replaFHment, press Reset button before using the remote control.
2
HYE-W01
