Enhanced Micro TDC 3000 User’s Manual 5-25 9/95
5.4.3
5.4.3 HITACHI Model HM-4821-D
Subsection 5.4.3 describes the operational controls of the Hitachi 21-inch monitor (Model
HM-4821-D). The location and basic function of each panel screen control is shown in
Figures 5-5, 5-6, and 5-7.
53949
RGB123COLOR
–+–+2
DEGAUSS POWER
ON
ADJUST
–+
MODE
1
STORE RECALLSELECT
GREEN ORANGE:SAVE
Figure 5-5 — Location of Front Panel Controls for Hitachi 4821-D
