Enhanced Micro TDC 3000 User’s Manual 6-8 9/95
6.2.3
6.2.3 21-Inch Monitor Adjustments
The analog, rotary-type screen control knob adjustments for the IDEK 21-inch Multiscan
color monitor are located on the front, just below the screen. The digital, push-button
screen control adjustments for the IDEK 21-inch Vision Master color monitor are located
inside a recessed, sliding tray (drawer) located below the screen. These adjustments are
summarized in Table 6-2.
Table 6-3 — 21-inch Monitor Adjustments
CONTROL ADJUSTMENT
Brightness Turn knob or press button to adjust the brightness of the display
Contrast Turn knob or press button to adjust the contrast of the display
Raster rotation Turn knob or press button to correct the raster tilt of the display
Pincushion correction Turn knob or press button to correct both the right and left side
distortion of the display
Vertical size Turn knob or press button to adjust the vertical size of the
display
Vertical position Turn knob or press button to adjust the center of the display
vertically
Horizontal size Turn knob or press button to adjust the horizontal size of the
display
Horizontal position Turn knob or press button to adjust the center of the display
horizontally
Signal select switch (three-
position switch)
VGA: Select VGA when using a VGA graphics card
MACII: Select MACII when using an Apple Macintosh or PGC
graphics card.
OTHER: Select OTHER when using any other graphics card or
generator than the above, with a horizontal frequency
between 30 and 80 khz.
For the UWS, place this switch in the MACII position.
Degauss Press this button to degauss the CRT
