Enhanced Micro TDC 3000 User’s Manual 6-10 9/95
6.5
• Note that the front (large) boards can be accessed through the front of each tower
by removing the front cover. Remove it by grasping the edges of the panel near the
bottom and pulling straight out. With the front cover removed, inspect the
confidence indicators on each node’s processor (see Figure 3-1). Check the power
supply and fan confidence indicators. To replace the cover, slip it under the top
front edge and snap it into the two bottom spring catches.
• The small I/O or paddle boards (see Figure 2-3) are accessed from the rear through
a center panel held in place with four M5 screws.
• If the history module is the only application not working, check the Winchester
power supply in the bottom of tower #2—the circuit breaker on the supply may be
off. Access this breaker through the rear center-section of tower #2.
To isolate a failed board, power supply, fan assembly, or other Optimum Replaceable Unit
(ORU), follow the service procedures provided in the 8-Node Multinode Module Service
manual in the Implementation/8-Node Enhanced Micro TDC 3000 binder.
Service Information for the cartridge drives and the ASPI-41 printer is provided in
Universal Station Service in the LCN Service - 1 binder.
6.5 SPARE PARTS
Table 6-4 — Parts List
PART NUMBER DESCRIPTION
51196739-100 Document Reference Micro TDC Configurations
* 51195652-100 20" CRT Color Monitor
51195904-006 20" CRT I/C CABLE Cable from Transition Panel to CRT
51190921-100 20" CRT POWER CORD 120 V Power Cord for CRT
51190921-200 20" CRT POWER CORD 240 V Power Cord for CRT
* 51196075-100 21" CRT 21-Inch FST Desk-Top Color Monitor
* 51196363-100 21" CRT 21-Inch Multi-Sync CRT Color Monitor
* 51197007-100 TOUCHSCREEN FOR 21" CRT T/S for 21" FST Desk-Top Color Mon. (1)
51197019-100 TOUCHSCREEN FOR 21" CRT T/S for 21" Multi-Sync Color Monitor (1)
* 51197005-100 CONTROL BOX Control Box for 21" Touchscreen (1)
51195904-XXX CABLE SET Video Copier to EPDG Cable
* 51302287-100 MICRO CABLE Micro cable for 21" Touchscreen (1)
* 51302297-100 UTDC CABLE UTDC cable for 21" Touchscreen (1)
* 51108385-508A M4X8 SCREWS-21" TCH SCRN Cable connector Screws at M/F (1)
* 51195904-106 21" CRT CABLE 21-Inch RT Data Cable
51303654-092 AC 125 V POWER CORD AC Cable for Winchester Power Supply
51303655-092 AC 250 V POWER CORD AC Cable for Winchester Power Supply
* 51201201-600 AIR FILTER Air Filter in the top of each tower
* 51108305-100 ASPI 41 PRINTER Printer
(Continued)
* ORU Level Replacement Item
(1) Complete 21" Touchscreen Asm. available by ordering: MX-MTTS11-100 (not including monitor)
