2.7.14 Cabling Diagram and Parts List – Touchscreen
If the touchscreen special has been installed, the following figure and table represents the
cabling.
53418
Engineering
Keyboard
Enclosure
Operator Keyboard
Monitor
Printer
Cartridge Drive 0
EPDGC I/O
Video
Cursor
Printer
SCS
I
Keyboar
d
1
4
5
2
7
6
Touch Screen
Power Supply
or Five-slot
Module J8
8
9
Cartridge Drive 1
10
11
Control
3
Figure 2-15 — Enhanced Micro TDC 3000 Cabling — Touchscreen
Table 2-3 — Micro TDC 3000 Cabling — Touchscreen
Ref. # Part Number Application Notes
1 51192126-200 Video Cable
2 51308097-100 Touchscreen Interface Cable
3 51308114-100 Touchscreen Interface Cable
4 51308103-003 Printer Cable – 3 meters/9.8 ft.
51308103-008 Printer Cable – 8 meters/26.3 ft.
51308103-015 Printer Cable – 15 meters/49.2 ft.
5 51192054-101 Cable,SCSI Shielded, 50 position
6 51305070-200 Cable, SCSI
7 51308110-100 Cartridge Drive Power Cable
8 51308109-100 Cartridge Drive Power Cable (in Enclosure)
9 51308105-200 Keyboard Interconnecting Cable
10 51308104-100 Keyboard Interface Cable (in Keyboard Tray)
11 51304496-046 Engineer"s Keyboard Cable (in Keyboard Tray)
