Enhanced Micro TDC 3000 User’s Manual 2-3 9/95
2.3.3
2.3.3 Current in Amperes at 120 Vac
Avg True RMS Peak Wattage BTUs/hr
Twr #1 (1 US, AM, NIM, & drives) typical 1.65 3.53 10 266 907.06
Twr #1 (2 US, AM, NIM, & drives) typical 1.95 4.12 11.2 319 1087.79
Twr #1 (1 US, AM, NIM, CG, & drives) typical 2.01 4.25 11.4 329 1121.89
Twr #2 (HM only) typical 1.15 2.54 6.5 185 630.85
Twr #2 (HM & US) typical 1.54 3.34 9.5 249 849.09
Twr #2 (HM, US, & US) typical 1.84 3.91 10.7 299 1019.59
Twr #2 (HM, US, & CG) typical 1.95 4.12 11.2 319 1087.79
Monitor, 20 inch CRT typical 0.5 1.14 3.1 79 269.39
Monitor, 21 inch CRT typical 0.8 1.5 4.1 83 283
ASPI-41 Printer typical 1.1 1.75 9.1 210 716
For Advanced Process Manager power consumption, consult Process Manager /Advanced
Process Manager Planning, part of the System Site Planning - 1 binder.
2.4 UNPACKING
When the equipment arrives at the system site, open each shipping box, remove the
protective wrapping and carefully inspect each piece for any physical damage. If damaged,
immediately notify the carrier and your Honeywell sales representative as to the extent and
type of damage. Also check each piece of equipment against the invoice list for any missing
items.
CAUTION
Optional touchscreens will be factory installed. Be careful not to lift the CRTs by holding the
touchscreen bezel. Due to the weight you may easily damage the touchscreen.
