Enhanced Micro TDC 3000 User’s Manual 5-13 9/95
5.4
5.4 MONITOR OPERATION
The Enhanced Micro TDC 3000 may be using one of following types of monitors:
• IDEK 21–inch Multiscan Color Monitor (older monitor Model MF-5221). Section
5.4.1 explains the analog, rotary-type screen control knobs.
• IDEK 21–inch Vision Master Monitor (newer monitor Model MF-8221). Section
5.4.2 explains the digital, push-button screen controls.
• HITACHI 21–inch Color Monitor (Model HM-4821-D). Section 5.4.3 explains
the screen controls. This monitor meets CE requirements. It must be ordered
separately using model number MX-MTMA21.
The newer IDEK monitor is essentially identical to the older monitor including the
touchscreen option. There are small physical differences between them primarily in the
layout and location of the screen controls. The new monitor has its screen controls
mounted inside a recessed, sliding tray (drawer) located below the screen. The screen
controls on the new monitor cannot be accessed once the drawer is closed (pushed in). The
overall dimensions of the newer monitor are slightly larger than the older monitor.
Electrically, the video cable plug and pinning are identical in both.
Both IDEK monitors have an optional touchscreen (infrared touchscreen frame with plastic
bezel assembly) which are physically different. The touchscreen option for the newer
monitor has 4 mounting ‘buttonholes’ (two on each side), and is only compatible with the
newer monitor. The older monitor has 2 ‘buttonholes’ (one on each side). The
touchscreen controller (electronics) and cable for the new monitor is identical to the older
monitor and can be easily transferred.
Table 5-1 shows the touchscreen hardware used with each monitor. The only difference
between the two IDEK monitors is the larger Bezel for the newer IDEK Model 8821. The
Hitachi uses the same touchscreen frame as the IDEK monitors.
Table 5-1 — Touchscreen Hardware Vs Monitor Used
Touchscreen
Components
Hitachi
HM-4821-D
51197021-100
IDEK
8221
51196363-100
IDEK
5221
51196075-100
MITSUBISHI
HC3905ATK
51195652-100
T/S Controller 51197005-100 51197005-100 51197005-100
Cable: EPDGP I/O
to Controller
51302287-100 51302287-100 51302287-100 51306150-100
②
TS Power Cable
Cable: Controller to
Touchscreen
51302297-100 51302297-100 51302297-100 51306151-100
②
TS Data Cable
Touchscreen w/Bezel 51197022-100
➃
51197019-100
➃
51197007-100
➃
51195992-100
Bezel only 51197022-300
➂
51197019-200
①
Bezel mounting
buttons-pkg of 4
51197022-400 51197019-300
①
Notes:
① These two items are required when moving a touchscreen from an IDEK model 5221 to a IDEK model 8221.
The IDEK 8221 requires a slightly larger plastic bezel housing. The same touchscreen (sensor) frame is
used in both IDEKs and the Hitachi. The four stick on buttons physically secure the touchscreen to the
monitor.
② These cables go from the touchscreen to the I/O card in the node chassis.
➂ Includes the 4 mounting buttons. This Bezel will adapt either IDEK touchscreen to fit the Hitachi monitor
➃ These assemblies all contain the same touchscreen. Only the Bezel is different.
