Honeywell EXCEL 5000 User Manual

EXCEL CARE CONTROL ICONS
273 74-5577–31 (US)
EN2B-0184 GE51 R0516 Europe)
APPENDIX A: PARAMETER LIST DESCRIPTION
Description When you translate a plant in CARE, CARE generates a parameter list file that
documents the parameters used in the control strategy and switching logic for the
plant.
You can use this reference list after the CARE process is complete and you are
testing the controller with the XI584 Operator Terminal. See also the XI584 Portable
Operator´s User Guide and the CARE User Guide for detailed descriptions of the
printout.
Example
Main 1 Main module : M0
Module 2 Parameter file number : 0
List 3
4 P.Nr | Description | Value + Eng. Unit | Symbol Reference
5 ---------------------------------------------------------------------------------
6 1 | Internal use | 0.000 | |
7 2 | Internal use | 1.000 | |
8
Control 9 Plant :ah1
Loop 10 Control loop :loop1
List 11 Parameter file number :1
12
13 P.Nr | Description | Value + Eng. Unit | Symbol Reference
14 ---------------------------------------------------------------------------------
15 1 | Internal use | 0.000 |
16 2 | Internal use | 1.000 |
17 3 | Proportional band (Xp) | 12.000 | 2.1
18 4 | Derivate time (TV) | 0.000 | 2.1
19 5 | Internal use | 1000.000 | 2.1
20 6 | Minimum output | 0.000 | 2.1
21 7 | Maximum output | 100.000 | 2.1
23 8 | Integral action time (Tn) | 1000.000 | 2.1
24
Switch. 25 Plant : ah1
Table 26 Switching table : MaDmpr
List 27 Parameter file number : 2
28
29 P.Nr | Description | Value + Eng. Unit | Symbol Reference
30 ----------------------------------------------------------------------------------
-
31 1 | Internal use | 0.000 |
32 2 | Internal use | 1.000 |
33 3 | Hysteresis of Line 1 Table 1 | 5.000 | 1
34 4 | Comparison Value 2 of Line 1 Table 1 | 32.000 | 1
35 5 | Hysteresis of Line 2 Table 1 | 3.000 | 1
36 6 | Comparison Value 2 of Line 2 Table 1 | 55.000 | 1
37 7 | Hysteresis of Line 1 Table 2 | 5.000 | 2
38 8 | Comparison Value 2 of Line 1 Table 2 | 32.000 | 2
39 9 | Hysteresis of Line 2 Table 2 | 3.000 | 2
40 10 | Comparison Value 2 of Line 2 Table 2 | 55.000 | 2
41 11 | On-Delay of Column 1 Table 3 | 31.000 Sec | 3
42 12 | Hysteresis of Line 1 Table 3 | 5.000 | 3
43 13 | Comparison Value 2 of Line 1 Table 3 | 32.000 | 3
44 14 | Hysteresis of Line 2 Table 3 | 3.000 | 3
45 15 | Comparison Value 2 of Line 2 Table 3 | 55.000 | 3
46 16 | Output Value Table 3 | 100.000 | 3
47 17 | Output Value Table 2 | 50.000 | 2
48 18 | Output Value Table 1 | 0.000 | 1
49
50 Plant : ah1
